PART NO.
DESCRIPTION
M100075BRB90
1" Flange x 3/4" Hose Barb 90° Elbow
M100BRB90
1" Flange x 1" Hose Barb 90° Elbow
M100125BRB90
1" Flange x 1-1/4" Hose Barb 90° Elbow
M200100BRB90
2" Flange x 1" Hose Barb 90° Elbow
M200125BRB90
2" Flange x 1-1/4" Hose Barb 90° Elbow
M200150BRB90
2" Flange x 1-1/2" Hose Barb 90° Elbow
M200BRB90
2" Flange x 2" Hose Barb 90° Elbow
PART NO.
DESCRIPTION
M100075BRB
1" Flange x 3/4" Hose Barb
M100BRB
1" Flange x 1" Hose Barb
M100125BRB
1" Flange x 1-1/4" Hose Barb
M200100BRB
2" Standard Port Flange x 1" Hose Barb
M200125BRB
2" Standard Port Flange x 1-1/4" Hose Barb
M200150BRB
2" Standard Port Flange x 1-1/2" Hose Barb
M200BRB
2" Standard Port Flange x 2" Hose Barb
PART NO.
DESCRIPTION
M100075MPT
1" Flange x 3/4" Male Thread
M100MPT
1" Flange x 1" Male Thread
M100125MPT
1" Flange x 1-1/4" Male Thread
M200125MPT
2" Standard Flange x 1-1/4" Male Thread
M200150MPT
2" Standard Flange x 1-1/2" Male Thread
M200MPT
2" Standard Flange x 2" Male Thread
PART NO.
DESCRIPTION
FC100
100 Series Worm Screw Clamp
FC200
200 Series Standard Port Worm Screw Clamp
FC220
220 Series Full Port Worm Screw Clamp
FC300
300 Series Worm Screw Clamp
M100G
100 Series EPDM Gasket
M100GV
100 Series FKM (viton type) Gasket
150G
200 Series Standard Port EPDM Gasket
150GV
200 Series Standard Port FKM (viton type) Gasket
ASSEMBLIES
H25 - 2HC0008 #
D10 - 2HC0195
PUMP SUCTION FITTINGS
2-PIECE SUCTION ASSEMBLY
#
#
#
#
